Products產品介紹
| 品牌 | 建準SUNON |
|---|---|
| 型號 | SF11580AT 1082HSL.GN, SF11580AT 1082HBL.GN, SF23080AT 2082HSL.GN, SF23080AT 2082HBL.GN |
| 規格 |
備註
17~22CFM
產品介紹
檔案下載
| Model | SF11580AT-1082HBL.GN |
|---|---|
| Length (mm) | 80 |
| Width (mm) | 80 |
| Thickness (mm) | 25 |
| Size L x H x W (mm) | 80X80X25 |
| Voltage | 115 |
| Bearing Type | 2BALL |
| Frequency (Hz) | 50/60 |
| Power Current (mA – VDC, Amp – VAC) | 0.12/0.10 |
| Power Consumption (Watts) | 12/11 |
| RPM (Speed) | 2450/2900 |
| CFM (Air Flow) | 18/22 |
| Static Pressure (Inch_H2O) | 0.13/0.19 |
| Noise (DBA) | 30/34.5 |
| Weight (g) | 260 |
| Model | SF11580AT-1082HSL.GN |
|---|---|
| Length (mm) | 80 |
| Width (mm) | 80 |
| Thickness (mm) | 25 |
| Size L x H x W (mm) | 80X80X25 |
| Voltage | 115 |
| Bearing Type | SLEEVE |
| Frequency (Hz) | 50/60 |
| Power Current (mA – VDC, Amp – VAC) | 0.12/0.10 |
| Power Consumption (Watts) | 12/11 |
| RPM (Speed) | 2300/2750 |
| CFM (Air Flow) | 17/21 |
| Static Pressure (Inch_H2O) | 0.12/0.18 |
| Noise (DBA) | 29/33 |
| Weight (g) | 260 |
| Model | SF23080AT-2082HBL.GN |
|---|---|
| Length (mm) | 80 |
| Width (mm) | 80 |
| Thickness (mm) | 25 |
| Size L x H x W (mm) | 80X80X25 |
| Voltage | 220 |
| Bearing Type | 2BALL |
| Frequency (Hz) | 50/60 |
| Power Current (mA – VDC, Amp – VAC) | 0.07/0.07 |
| Power Consumption (Watts) | 14/13.5 |
| RPM (Speed) | 2450/2900 |
| CFM (Air Flow) | 18/22 |
| Static Pressure (Inch_H2O) | 0.13/0.19 |
| Noise (DBA) | 30/34.5 |
| Weight (g) | 260 |
| Model | SF23080AT-2082HSL.GN |
|---|---|
| Length (mm) | 80 |
| Width (mm) | 80 |
| Thickness (mm) | 25 |
| Size L x H x W (mm) | 80X80X25 |
| Voltage | 220-240 |
| Bearing Type | SLEEVE |
| Frequency (Hz) | 50/60 |
| Power Current (mA – VDC, Amp – VAC) | 0.07/0.07 |
| Power Consumption (Watts) | 14/13.5 |
| RPM (Speed) | 2300/2750 |
| CFM (Air Flow) | 17/21 |
| Static Pressure (Inch_H2O) | 0.12/0.18 |
| Noise (DBA) | 29/33 |
| Weight (g) | 260 |
